COMPOUND & MASTERBATCH  TECHNOLOGIES

Gantry Pelletizer (Gear  Reduction type)

Gantry Pelletizer (Belt Drive type)

• Hard alloy blade,

• Hard alloy rotor cutter,

• All parts contacts with materials are made of stainless steel
  304,

• Drived by belt reduction,

• Rotor material and angel were designed according to the
  material,

• Rubber or polyurethane roller,

• Safety interlock to protect the operator,

• Standard pellet size is 3x3mm, can be designed according to
  customer requirements,


• Hard alloy blade,

• Hard alloy rotor cutter,

• All parts contact with materials are stainless steel 304,

• Drived by Nord motor with gear reduction, low noise, run stable,

• Rotor material and angel were designed according to the
  material,

• Rubber roller with good temperature and wearing resistance,
  cooling device for the rubber rolling to make longer life,

• Special design to prevent the pellets running out from the
  chamber, with air purge device, easy cleaning,

• Safety interlock to protect the operator,

• Standard pellet size is 3x3mm, can be designed according to
  customer requirements,

• Noise seperator (optional),
